Oakvale Road PSD Water Project Experience

Location: Mercer County, West Virginia

Project: I 77/U.S. Route 460 Economic Development Project Study, Design Construction Administration and Inspection
150,000 gallon water storage tank
Distribution lines to serve private industrial development and tourist center with booster station system to be operated by WV American Water Company
Est. Cost: $1,300,000
Status: Complete

Project: Mercer/Summers Phase IV-A Waterline Extensions – Over 25 miles of 2” through 12” waterlines with appurtenances, pressure reducing stations, booster station and water storage tank. Service to 407 new customers
Est. Cost: $6.4 Million
Status: Completed 2012

Project: Mercer/Summers Phase IV-B Waterline Extension – 13 miles of 2” through 10” waterlines with appurtenances, pressure reducing and booster stations and water storage tank. Service to 128 new customers
Est. Cost: $2.6 Million
Status: Partial Substantial Completion Achieved

Photos

Client:
Oakvale Road PSD

Service Type:
Civil Engineering

Project Value:
N/A

Completion Date:
N/A

Project Area:
N/A

Town of Rainelle, WV Water Project Experience

Location: Greenbrier County, West Virginia

Project: Design and Construction period services for water system and treatment plant renovations. Extension & replacement of 2.3 miles of 2” – 8” waterlines and appurtenances, 160 existing customer meter reconnects, 8 new customer services, design of existing plant upgrades with aerator, one four-cell horizontal pressure filter, and one pressure detention tank.
Est. Cost: $2,675,000
Status: Completed March 2016

Project: Design, construction administration and inspection for water system renovation.
150,000 gallon storage tank
4,500 feet of distribution lines
Est. Cost: $240,000
Status: Begin -1985 Operational 1986

Photos

Client:
Town of Rainelle, WV

Service Type:
Civil Engineering

Project Value:
N/A

Completion Date:
N/A

Project Area:
N/A

Water Storage Experience

The following is a sampling of T&L’s Water Storage Projects:

City of Bedford ñ 1.5 Million Gallon Underground Water Storage Tank Rehabilitation

City of Bedford – Water Filtration Storage Tank Evaluations

City of Bedford – 1.0 Million Gallon Underground Water Storage Tank Rehabilitation

Buchanan County PSA – Fletcherís Ridge Pump Station/Water Storage Tank

Dickenson County PSA – Hazel Mountain Water – Nealy Ridge Storage Tank

Giles County BOS – Hoges Chapel/Newport Water Storage Tank

Russell County Water & Sewer Authority – Red Oak Water Storage Tank

Tazewell County PSA – Pounding Mill Water Storage Tank

Tazewell County PSA – Reynolds Ridge and Stinson Ridge Water Storage Tank

Tazewell County PSA – Rt. 609 Water Storage Tank

Tazewell County PSA – Hawks Heights 400,000 Gallon Water Storage Tank

Tazewell County PSA – Springville Water Storage Tank

Town of Richlands – Birmingham Water Storage Tank

Town of Richlands – Water Storage Tanks

Town of Richlands – Richlands Downtown Water Storage Tank

Bland County BOS – Rocky Gap Water System Storage Tank

Town of Wise Modoc Water Tank Rehabilitation Work

Town of Lebanon ñ 2.00 MG Concrete Water Storage Tank

Dickenson County PSA – Elevated Tank

Photos

Client:
Various Municipalities

Service Type:
Civil Engineering

Project Value:
N/A

Completion Date:
N/A

Project Area:
N/A

Town of Wise – Bear Creek Reservoir

The Town of Wise owns and operates the Bear Creek Reservoir, constructed in 1964 at 45-feet high and holding approximately 808 acre-feet of water. This impoundment was constructed as a water supply reservoir for the Town and surrounding areas.

In 2003, the Town retained Thompson & Litton (T&L) to determine the water supply needs for 25 years ending in 2028. This study determined that the capacity of the reservoir needed to be increased in order to supply predicted water needs throughout the planning period.

In 2007, T&L was again retained to determine the best means to increase the storage of water by the Bear Creek Dam. This study also determined that the spillway must be enlarged to pass the entire Probable Maximum Flood (PMF) due to potential damage that would result if the dam breached. Following is a summary of the findings from the 2007 Study:

Determined the best alternative spillway to pass the PMF. It was concluded that allowing the flood to overtop the dam and armoring the entire downstream face of the dam with roller compacted concrete was the best option; and
Determined the best way to increase the capacity of the reservoir. Raising the normal pool elevation by five feet provided the required additional storage.

In 2008, the Town retained T&L to design the repairs identified in the 2007 study. The following corrections were designed, and construction began in 2011:

Construction of a roller compacted concrete armoring of the entire downstream face of the dam;
Added a structural concrete parapet wall, raising the normal pool elevation by 5 feet and adding eighty million gallons to the storage, which increased the safe yield of the watershed; and
Raised the concrete primary outlet to accommodate the increase in normal pool elevation, and replaced the gates and hardware in the primary outlet for operability and reliability.

Photos

Client:
Town of Wise

Service Type:
Civil Engineering

Project Value:
$3 Million

Completion Date:
2012

City of Summersville, WV – Water Project Experience

Project: U.S. Route 19 Economic Development Center Upgrading – study, design, construction administration and inspection of distribution lines, water storage facilities, sewage treatment plant upgrading & collection system.

Est. Cost: $3,200,000
Status: Complete

Project: Glade Creek Phase I – Waterlines
Est. Cost: $1,700,000
Status: Operational 1999

Project: Summersville Regional Water Project – five contracts consisting of a raw water intake, new water treatment facility, water storage tank, distribution lines, 2.6 miles of 2” through 16” waterlines with appurtenances, 30 customers, 1,750 LF 16” raw waterline, 322,000 gallon bolted water storage tank and site, 2,000 gpm water treatment plant, raw water intake
Est. Cost: $11,000,000
Status: Operational 2004

Project: Glade Creek Phase IIA – Waterlines – five contracts consisting of water storage tank, distribution lines and service. 23 miles of 2” through 12” waterlines with appurtenances, 102,000 gallon welded water storage tank and site, 181 customers.
Est. Cost: $6,227,445.99
Status: Operational 2012

Project: Glade Creek Phase IIB – two contracts consisting of distribution lines and services, directionally drilled controlled access highway crossing. 9 miles of 2” through 8” waterlines and appurtenances, 100 customers.
Status: Completed 2015

Photos

Client:
City of Summersville, WV

Service Type:
Civil Engineering

Project Value:
N/A

Completion Date:
N/A

Project Area:
N/A
